Diode LED introduces BLAZE™ Basics WET - our new value engineered LED Wet Location tape light leveraging the advances in efficient, cleaner technology, newer circuit design, streamlined manufacturing, and economies of scale. Featuring 90+ CRI, this enhanced version of the popular BLAZE and FLUID VIEW Tape Light families is backed by a 7-year warranty and the well known service and support of Diode LED at an extremely attractive price point. This new low voltage led lighting for indoor task lighting and display lighting is built on the same dependable LED tape and strip light format you are used to working with from Diode LED.
BLAZE BASICS WET
SPECIFICATIONS		 BLAZE BASICS WET STRIP LIGHT CONNECTORS ELEMENT OUTDOOR
MOUMTING CHANNEL		 BLAZE BASICS WET
POWER SUPPLIES and CONTROLS

Blaaze
Blaze
CLICK any ICON Below for Full Explanation:
ETL Field RoHS 24V 24V No Indoor Dimmable
ETL
CERTIFIED		 FIELD
CUTTABLE		 RoHS
COMPLIANT		 BLAZE BASICS WET DO NOT CONNECT TO
120V AC		 Indoor
Use Only		 Dimmable
12V DC 24V DC
• Kitchen cabinet, under cabinet, shelf, and case lighting
• Exhibit, presentation, and project lighting
• Close application task lighting
• Cove and interior accent lighting
• Shop windows, window displays, display case lights, and uplighting
• Light boxes and interior signage

Click Button for PDF SOLID COLOR Installation Guide PDF
Click Button for BLAZE BASICS WET 100 Low Output LED PDF Specifications BLAZE
Click Button for BLAZE BASICS WET 200 High Output LED PDF Specifications BLAZE
Click Button for Full 7 Year
Warranty Information		 Diode
TECH SPECS
Sold in 16.4' or 100' Spools Width : 0.39 in. / Height: 0.18 in.
100% Dimmable Operating Temp7: -4 ~ 176°F (-20 ~ 80°C)
Color Temperature Range: 2700K, 3000K, 5000K LED Type: 2835 Guang Mau Chip
Beam Angle: 120° LED Spacing: 0.3 in. between centers
Working Voltage: 12VDC or 24V DC Lifespan: 50,000+ hours
LEDs Per Foot : BASIC 100 WET - 18;
BASIC 200 WET - 36		 Lumens Per Foot: 116 - 280
IP Rating: Indoor / Wet Location UV/IR Radiation: None
Connectors: 16.4 ft. spools come with 3 foot bare lead wires on one end and a 12 inch white, female DC plug on the other end; 100 ft. spools come with 3 foot bare lead wires on both ends
BASICS 100 WET Max. Run: 12V - 27': 24V 55' BASICS 200 WET Max. Run: 12V - 20':' 24V 40'
COLOR TEMPERATURE ILLUSTRATION
KChart
I
ITEM LENGTH OUTPUT VOLATGE LUMENS
/ FT		 COLOR COLOR
TEMP.		 CRI* POWER
CONS / FT		 LEDS
/ FT		 PRICE
12V BLAZE BASICS 100 WET
DI-12V-BLBSC1-27-W016 16.4 ft. / 5m 12VDC 107 warm white 2700K 90+ 1.46W 18 $161.10
DI-12V-BLBSC1-27-W100 100 ft. / 30.4m 12VDC 107 warm white 2700K 90+ 1.46W 18 $891.00
DI-12V-BLBSC1-30-W016 16.4 ft. / 5m 12VDC 116 warm white 3000K 90+ 1.46W 18 $161.10
DI-12V-BLBSC1-30-W100 100 ft. / 30.4m 12VDC 116 warm white 3000K 90+ 1.46W 18 $891.00
DI-12V-BLBSC1-50-W016 16.4 ft. / 5m 12VDC 116 cool white 5000K 90+ 1.46W 18 $161.10
DI-12V-BLBSC1-50-W100 100 ft. / 30.4m 12VDC 116 cool white 5000K 90+ 1.46W 18 $891.00
24V BLAZE BASICS 100 WET
DI-24V-BLBSC1-27-W016 16.4 ft. / 5m 24VDC 106 warm white 2700K 90+ 1.46W 18 $161.10
DI-24V-BLBSC1-27-W100 100 ft. / 30.4m 24VDC 106 warm white 2700K 90+ 1.46W 18 $891.00
DI-24V-BLBSC1-30-W016 16.4 ft. / 5m 24VDC 114 warm white 3000K 90+ 1.46W 18 $161.10
DI-24V-BLBSC1-30-W100 100 ft. / 30.4m 24VDC 114 warm white 3000K 90+ 1.46W 18 $891.00
DI-24V-BLBSC1-50-W016 16.4 ft. / 5m 24VDC 114 cool white 5000K 90+ 1.46W 18 $161.10
DI-24V-BLBSC1-50-W100 100 ft. / 30.4m 24VDC 114 cool white 5000K 90+ 1.46W 18 $891.00
12V BLAZE BASICS 200 WET
DI-12V-BLBSC2-27-W016 16.4 ft. / 5m 24VDC 206 warm white 2700K 90+ 2.93W 36 $278.10
DI-12V-BLBSC2-27-W100 100 ft. / 30.4m 24VDC 206 warm white 2700K 90+ 2.93W 36 $1,539.00
DI-12V-BLBSC2-30-W016 16.4 ft. / 5m 24VDC 221 warm white 3000K 90+ 2.93W 36 $278.10
DI-12V-BLBSC2-30-W100 100 ft. / 30.4m 24VDC 221 warm white 3000K 90+ 2.93W 36 $1,539.00
DI-12V-BLBSC2-50-W016 16.4 ft. / 5m 24VDC 227 cool white 5000K 90+ 2.93W 36 $278.10
DI-12V-BLBSC2-50-W100 100 ft. / 30.4m 24VDC 227 cool white 5000K 90+ 2.93W 36 $1,539.00
24V BLAZE BASICS 200 WET
DI-24V-BLBSC2-27-W016 16.4 ft. / 5m 24VDC 209 warm white 2700K 90+ 2.93W 36 $278.10
DI-24V-BLBSC2-27-W100 100 ft. / 30.4m 24VDC 209 warm white 2700K 90+ 2.93W 36 $1,539.00
DI-24V-BLBSC2-30-W016 16.4 ft. / 5m 24VDC 226 warm white 3000K 90+ 2.93W 36 $278.10
DI-24V-BLBSC2-30-W100 100 ft. / 30.4m 24VDC 226 warm white 3000K 90+ 2.93W 36 $1,539.00
DI-24V-BLBSC2-50-W016 16.4 ft. / 5m 24VDC 224 cool white 5000K 90+ 2.93W 36 $278.10
DI-24V-BLBSC2-50-W100 100 ft. / 30.4m 24VDC 224 cool white 5000K 90+ 2.93W 36 $1,539.00
* COLOR RENDERING INDEX
WET LOCATION CONNECTORS
DI-10MM-WL-SCP
DI-10MM-WL-DC-F
DI-10MM-WL-DC-M
DI-10MM-WL6-EXT
DI-10MM-WL12-EXT
DI-10MM-WL24-EXT
DI-10MM-WLSP2
DI-10MM-WLSP3
DI-10MM-WLSP5
DI-0755 / DI-WPSL
SCP DI-10MM-WL-DC-F DI-0725 DI-10MM-WLSP2 DI-0762
Wet Location
Splice Connector Pair 		Wet Location Female / Male
Connector		 Wet Location Male-to Female
6" / 12" / 24" Extension Cable		 We t Location
2-Way / 3-Way / 5-Way
Splitter		 Waterproof End Caps
Waterproof Sealant
Connects the Light Strip to a Hard-Wired Driver.
Connects the Light Strip to a Plug-In Adapter and other DC accessories.
Creates an extension between Light strips and Poser Supplies.
Creates an connection for multiple Light strips and Poser Supplies.
Pack of 10 End Caps.

45g Tube of Sealant.
3.0” Length 0.3” Length 6" / 12" / 24" Length
$4.50
$8.10
$8.10
Length Price
6" $4.50
12" $7.20
24" $8.10
Item Price
2-WAY $8.10
3-WAY $9.90
5-WAY $12.15
$5.40 / $8.10

CLICK IMAGE for LARGER VIEW
